Sin existencias
Sin existencias
– Diseño del circuito DC-DC El diseño del circuito DC-DC ofrece a su sistema voltajes de salida más confiables y estables, proporcionando una entrega de potencia más uniforme a hasta 40 ° C.
– Capacitores de alta Calidad
| Product Name | MWE Bronze 500 | |
| Product Number | MPX-5001-ACAAB | |
| ATX Version | Intel ATX 12V V2.31 | |
| PFC | Active PFC | |
| Operation Voltage | 100-240 Vac | |
| Input Voltage | 100-240 Vac | |
| Input Current | 8-4 A | |
| Input Frequency | 50-60 Hz | |
| Dimensions (LxBxH) | 140 x 150 x 86 mm | |
| Fan Size | 120 mm | |
| Fan Bearing | LDB | |
| Power Good Signal | 100-500 ms | |
| Hold Up Time | 16ms at 80% load | |
| Efficiency | 85% Typically | |
| ErP 2013 Lot 6 | Yes | |
| MTBF | >100,000 Hours | |
| Operating Temperature | 0~40°C | |
| Protections | OVP / OPP / OTP / SCP / OCP | |
| Regulatory | TUV-RH, CE, CCC, KC, EAC, RCM, cTUVus, FCC, BSMI | |
| Connectors | MB 20+4 Pin | 1 |
| CPU 12V 4+4 Pin | 1 | |
| SATA | 4 | |
| Peripheral 4 Pin | 3 | |
| FDD Cable 4 Pin | 1 | |
| PCI-e 6+2 Pin | 2 | |
